APPENDIX I: Specicaons in Other Languages | 43
X570GTA
Spanish
Especicaciones
Compabilidad con el
procesador
Ranura AM4 Soporta AMD® Ryzen APU/ Ryzen CPU
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el procesador.
Tipo de Placa AMD® X570
Memoria
Soporta DDR4 1866/2133/2400/2667 Doble Canal
Soporta DDR4 2933(OC)/3200(OC)/3600(OC)/4000+(OC) Doble Canal
4x DDR4 DIMM Ranura de memoria Soporta hasta 128 GB Memoria
Cada DIMM soporta un modulo non-ECC y ECC sin tampones 8/16/32 GB DDR4
* DDR4 - 2667 sólo para CPU Ryzen.
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el memoria.
Almacenamiento de
información
Conector 6x SATA III (6Gb/s): Soporta AHCI & RAID 0,1,10
1x M.2 (Key M):
Soporta SATA III (6.0Gb/s) SSD
Soporta PCI-E 4.0 x4 (64Gb/s), que depende solo de Ryzen 3ra Gen Masse.
LAN
RTL8111H
10/ 100/ 1000 Mb/s auto negociación, capacidad dúplex Mitad/Completo
Códec Audio
ALC887
Canales Audio de Alta Denición 7.1
USB
Ranura 8x USB 3.1 Gen1 (5Gb/s) - (4 en las entradas/salidas posteriores y 4 por los distribuidores internos)
Ranura 6x USB 2.0 (2 en las entradas/salidas posteriores y 4 por los distribuidores internos)
Ranuras de Exnción
Ranura 2x PCIe 3.0 x1
Ranura 1x PCIe 3.0 x16: Soporta el modo x4 (PEX16_2) :
Soporta carriles x4 con procesadores AMD® Ryzen™ de 2ª y 3ª generación.
Ranura 1x PCIe 4.0 x16 (PEX16_1)
* Nota :
Soporta carriles x16 (x16, x8) con procesadores AMD® Ryzen™ de 2ª y 3ª generación.
Soporta carriles x8 con AMD® Ryzen™ con procesadores Radeon Vega Graphics.
* Según diferentes CPUs tendremos diferentes velocidades.
* Nota: Velocidad PCIe 4.0 solo para AMD® Ryzen™ 3rd Gen Masse.
Panel trasero de E/S
Teclado 1x PS/2
Ranura 1x HDMI
Ranura 1x VGA
Ranura 1x LAN
Ranura 4x USB 3.1 Gen1 (5Gb/s)
Ranura 2x USB 2.0
Socket audio 3x
Conectores en placa
Conector 6x SATA III 6Gb’s
Distribuidor 2x USB 2.0 (cada distribuidor soporta 2 ranuras USB 2.0)
Distribuidor 2x USB 3.1 Gen1 (5Gb/s) -(cada distribuidor soporta 2 ranuras USB 3.1 Gen1)
Conector con 8 pallas x1
Conector con 24 pallas x1
Conector Venlador procesador x1
Conector Venlador Sistema x1
Conector Venlador Sistema x1 (Conector Venlador Disipador de calor Southbridge : Este conector solo
está disponible para el venlador de disipador de calor Southbridge.)
Distribuidor Panel Frontal x1
Distribuidor Audio Frontal x1
Distribuidor CMOS Directo x1
Distribuidor Ranura Serie x1
Distribuidor LED (12V/5V) x2
Factor de Forma
Factor de Forma ATX, 305 mm x 243 mm
Soporte OS
Windows 10(64bit)
Biostar reserva su derecho de añadir o rerar el soporte para cada OS con o sin nocación.
