4 | Chapter 1: Introducon
1�3 Specicaons
Specicaons
CPU Support
Socket 1151 for Intel® Core i7 / i5 / i3 / Penum / Celeron processor
Maximum CPU TDP (Thermal Design Power): 95Wa
* Please refer to www.biostar.com.tw for CPU support list.
Chipset INTEL® Z170 (Hi-Fi Z170Z5); INTEL® B150 (Hi-Fi B150Z5)
Memory
Supports Dual Channel DDR3L 1600/1333
2x DDR3L DIMM Memory Slot, Max. Supports up to 16 GB Memory
Supports Dual Channel DDR4 2133/1866
2x DDR4 DIMM Memory Slot, Max. Supports up to 32 GB Memory
* Please refer to www.biostar.com.tw for Memory support list.
** The motherboard will be damaged when you install DDR3L and DDR4 memory modules at same me.
Storage
INTEL® Z170:
1x SATA Express Connector (16Gb/s), 4x SATA III Connector
supports RAID 0,1,10, 5 & AHCI
INTEL® B150:
1x SATA Express Connector (16Gb/s), 4x SATA III Connector
supports AHCI
LAN Intel I219V, 1x 10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec ALC892, 7.1 Channels, High Denion Audio, Biostar Hi-Fi (Front+Rear)
USB
6x USB 3.0 port (4 on rear I/Os and 2 via internal header)
6x USB 2.0 port (2 on rear I/Os and 4 via internal header)
Expansion Slots
3x PCI Slot
1x PCIe 3.0 x1 Slot
1x PCIe 3.0 x16 Slot (x4)
1x PCIe 3.0 x16 Slot (x16)
Rear I/Os
1x PS/2 Keyboard/ Mouse
1x DVI-D Port
1x VGA Port
1x HDMI Port
1x LAN port
2x USB 2.0 Port
4x USB 3.0 Port
3x Audio Jack
Internal I/Os
1x SATA Express Connector
4x SATA III Connector
2x USB 2.0 Header
1x USB 3.0 Header
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
2x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x S/PDIF out Connector
1x COM Port Header
Form Factor ATX Form Factor, 305 mm x 225 mm
OS Support
Windows 7/ 8.1(64bit)/ 10(64bit)
Biostar reserves the right to add or remove support for any OS with or without noce.
