Chapter 1: Introducon | 5

Hi-Fi Z170Z5 / Hi-Fi B150Z5

1.4 Rear Panel Connectors

Note

 VGA,HDMI&DVI-DportsonlyworkwithanIntel®integratedGraphicsProcessor.

Maximumresoluon 

HDMI:4096x2160@24Hz,compliantwithHDMI1.4a

VGA:1920x1200@60Hz

DVI-D:1920x1200@60Hz

Themainboardsupportsthreeonboarddisplayoutputsatsamemeandthedisplayoutput 

conguraoncanbeselectedinIntelgraphicsdriverulity.

The 2/ 4/ 5.1/ 7.1-channel conguraon

Audio Port 2-channel 4-channel 5.1 channel 7.1 channel

A (Rear Panel) Line In Rear Speaker Out Rear Speaker Out Rear Speaker Out

B (Rear Panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out

C (Rear Panel) Mic In Mic In Center/Subwoofer Out Center/Subwoofer Out

Green (Front Panel) -- -- -- Side Speaker Out
