Planet WSW-2401A [7/95] Product specification

▫ High back-plane bandwidth 5Gbps

▫ Console/Web/SNMP management

▫ Configuration backup and recovery

▫ Per port Ingress/Egress bandwidth restriction

▫ Configurable spanning tree aging time, STP port configuration

▫ 12 trunk groups, up to 8 ports per trunk

▫ Port-based/802.1Q VLAN with 4K VLAN ID

▫ MAC Binding/Filtering/Learning, configurable MAC Aging time

▫ 8 mappings ID to 4 priority queues, Support MAC/VLAN/802.1p/Port to CoS mapping

▫ IGMP snooping for Multi-media application

▫ Statistic Routing Port

▫ 1 to many Ingress/Egress Port mirror and Port analysis

▫ Broadcast/Multicast/Flooded storm control

▫ 802.1X Port-Based Authentication

▫ IP Stack Technology supports up to 8unit switch stack for centralize management.

1.4 Product Specification

Hardware Specification

Network Connector 24-Port RJ-45 for 10/100Base-TX

1 open slot for 100Base-FX fiber-optic interface

RS-232 connector One RS-232 DB-9 male connector for switch management

Switch architecture Store and forward switch architecture.

Switch Fabric Back-plan up to 5Gbps

MAC address 8K MAC address table with Auto learning function

Shared Buffer 3Mbit

Power requirement 90~240V AC, 50/60Hz,

Operating environment 0 ~50 degree C, 5%~90%RH

Storage environment -20~70 degree C, 5%~90%RH

Dimension (W x D x H) 440 x 200 x 44 mm

Switch Specification

Spanning Tree 802.1d, 802.1w

Link Aggregation 12 groups, up to 8 ports per group

Priority Queue 802.1p Class of Service (4 Queues)

Port Mirror RX/TX/Both

Bandwidth Control Yes, per port per 64kbps, up to 80Mbps

Strom Control Per 64kbps, up to 80Mbps

IGMP Snooping V1

MAC Filtering Yes

LAN Port-Based/802.1Q, 4K VLAN ID, 256 groups

Port Analysis Yes

Static Routing Port Yes

Security 802.1X Port-Based Authentication
