[192.168.0.10] switch
Client connect to Ports those be assigned to VLAN 3 ,at
[192.168.0.20] switch
Client connect to Ports those be assigned to VLAN 3 ,at
[192.168.0.30] switch
VLAN 4 Client connect to Ports those be assigned to VLAN 4 ,at
[192.168.0.10] switch
Client connect to Ports those be assigned to VLAN 4 ,at
[192.168.0.20] switch
Client connect to Ports those be assigned to VLAN 4 ,at
[192.168.0.30] switch
WSW-2401A_192.168.0.222 Core-Switch VLAN Configuration
192.168.0.222 VLAN Configuration
Port Link Type PVID Egress Link Partner
Port1 Always Untag 1 Untag=1,2,3,4 Server
Port5 Trunk 1 Tag=1,2,3,4 192.168.0.30
Port6 Trunk 1 Tag=1,2,3,4 192.168.0.20
Port7 Trunk 1 Tag=1,2,3,4 192.168.0.10
WSW-2401A_192.168.0.10 Edge-Switch VLAN Configuration
192.168.0.10 VLAN Configuration
Port Link Type PVID Egress Link Partner
Port1 Always Untag 2 Untag=1,2 PC
Port2 Always Untag 3 Untag=1,3 PC
Port3 Always Untag 4 Untag=1,4 PC
Port18 Always Untag 1 Untag=1,2,3,4 NtworkPrinter
Port28 Trunk 1 Tag=1,2,3,4 Core-2840
WSW-2401A_192.168.0.20 Edge-Switch VLAN Configuration
192.168.0.20 VLAN Configuration
Port Link Type PVID Egress Link Partner
Port1 Always Untag 2 Untag=1,2 PC
Port2 Always Untag 3 Untag=1,3 PC
