Motherboard Manual
52
Spanish
Especificaciones
Compatibilidad con
el procesador
Ranura 1150 para procesador Intel® Core i7 / i5 / i3 / Pentium / Celeron
Alimentación de Proyección Térmica (TDP – Thermal Design Power): 95Watt
*Por favor consultar con
www.biostar.com.tw para la lista de compatibilidad con el
procesador.
Tipo de Placa INTEL® B85 (Hi-Fi B85N 3D) INTEL® H81 (Hi-Fi H81N 3D)
Memoria
Soporta DDR3 1066/ 1333/ 1600 Doble Canal
2x DDR3 DIMM Ranura de memoria Soporta hasta 16 GB Memoria
Cada DIMM soporta un modulo non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3
*Por favor consultar con
www.biostar.com.tw para la lista de compatibilidad con el
memoria.
Almacenamiento
de información
INTEL® B85:
Conector 2x SATA 6Gb/s
Conector 2x SATA 3Gb/s
Conector 1x mSATA 6Gb/s
Soporta AHCI
INTEL® H81:
Conector 1x SATA 6Gb/s
Conector 2x SATA 3Gb/s
Conector 1x mSATA 6Gb/s
Soporta AHCI
LAN
2x Realtek RTL 8111G
10/ 100/ 1000 Mb/s auto negociación, capacidad dúplex Mitad/Completo
Códec Audio
ALC892
Canales Audio de Alta Definición 7.1, Biostar Hi-Fi
USB
INTEL® B85:
Ranura 4x USB 3.0 (2 en las
entrada/salidas posteriores y 2 por los
distribuidores internos)
Ranura 8x USB 2.0 (4 en las
entrada/salidas posteriores y 4 por los
distribuidores internos)
INTEL® H81:
Ranura 2x USB 3.0 (2 en las entrada/salidas
posteriores)
Ranura 8x USB 2.0 (4 en las entrada/salidas
posteriores y 4 por los distribuidores
internos)
Ranuras de
Extinción
Ranura 1x PCIe 3.0 x16 (x16), Hi-Fi B85N 3D
Ranura 1x PCIe 2.0 x16 (x16), Hi-Fi H81N 3D
Panel trasero de
E/S
Teclado/Ratón 1x PS/2
Ranura 1x HDMI
Ranura 1x VGA
Ranura 1x DVI
Ranura 2x LAN
Ranura 4x USB 2.0
Ranura 2x USB 3.0
Socket audio 5x
Conector Externo S/PDIF x1
