![Biostar Hi-Fi A68U3P Версия 6.3 [4/48] Motherboard specifications](/views2/1708367/page4/bg4.png)
Motherboard Manual
2
1.3 Motherboard Specifications
Specifications
CPU Support
Socket FM2+ supports AMD FM2+ A-series APU
Maximum CPU TDP (Thermal Design Power): 100Watt
* Please refer to www.biostar.com.tw
for CPU support list.
Chipset AMD A68H FCH
Memory
Supports Dual Channel DDR3 800/ 1066/ 1333/ 1600/ 1866/ 2133/
2400(OC)/ 2600(OC)
2 x DDR3 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8/ 16 GB DDR3 module
* Please refer to www.biostar.com.tw
for Memory support list.
Storage 4x SATA 6Gb/s Connector : Supports RAID 0,1,10 & AHCI
LAN
Realtek RTL 8111G
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
Audio Codec ALC662, 5.1 Channels, High Definition Audio, Biostar Hi-Fi
USB
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
2x USB 3.0 port (2 on rear I/Os)
Expansion Slots
1x PCI Slot
1x PCIe x1 Slot
1x PCIe 3.0 x16 Slot (Only FM2+ processors can support PCIe 3.0)
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x VGA Port
1x HDMI Port
1x LAN port
2x USB 2.0 Port
2x USB 3.0 Port
3x Audio Jack
Internal I/Os
4x SATA III 6.0Gb/s Connector
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x Serial Port Header
Form Factor microATX Form Factor, 235 mm x 178 mm
OS Support
Windows XP / 7 / 8 / 8.1
Biostar reserves the right to add or remove support for any OS with or
without notice.
