Hi-Fi A85S3/Hi-Fi A75S3/Hi-Fi A55S3
49
Especificações
Conectores na
placa
Hi-Fi A85S3:
Conector 6x SATA 6.0Gb/s
Dispositivo 2x USB 2.0
Dispositivo 1x USB 3.0
Conector de 4 pinos x1
Conector de 24 pinos x1
Conector de Ventoinha
processador x1
Conector de Ventoinha Sistema
x1
Dispositivo Painel Frontal x1
Dispositivo de Audio Frontal x1
Dispositivo CMOS Direct x1
Dispositivo Porta Impressora x1
Dispositivo Porta Série x1
Hi-Fi A75S3:
Conector 6x SATA 6.0Gb/s
Dispositivo 2x USB 2.0
Dispositivo 1x USB 3.0
Conector de 4 pinos x1
Conector de 24 pinos x1
Conector de Ventoinha
processador x1
Conector de Ventoinha Sistema
x1
Dispositivo Painel Frontal x1
Dispositivo de Audio Frontal x1
Dispositivo CMOS Direct x1
Dispositivo Porta Impressora x1
Dispositivo Porta Série x1
Hi-Fi A55S3:
Conector 6x SATA 3.0Gb/s
Dispositivo 2x USB 2.0
Conector de 4 pinos x1
Conector de 24 pinos x1
Conector de Ventoinha
processador x1
Conector de Ventoinha Sistema
x1
Dispositivo Painel Frontal x1
Dispositivo de Audio Frontal x1
Dispositivo CMOS Direct x1
Dispositivo Porta Impressora x1
Dispositivo Porta Série x1
Fator de Fôrma Fator de Fôrma microATX, 244 mm x 191 mm
Suporte OS
Windows XP / Vista / 7/ 8
Biostar reserva seu direito de adicionar ou retirar o suporte para qualquer OS com ou
sem notificação.
