TPP 15A-D Series, 15 Watt

www.tracopower.com Page 3 of 4

All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.

General Specifications (continued)

Leakage current (at 264 VAC / 60Hz) 75 µA max.

Isolation resistance (at 500 VDC) 100 MOhm min.

Reliability – calculated MTBF at +25°C acc. to MIL-HDBK-217F 3‘063‘000 h

Weight 16.5 g (0.58 oz)

EMI emission – Conducted & Radiated input suppression EN 55011 limits to IEC 60601-1-2 4th edition

– Radiated immunity EN 61000-4-3, 20 V/m, perf. criteria A

– Fast transient EN 61000-4-4, ±2 kV, perf. criteria A

– Surge EN 61000-4-5, ±1 kV perf. criteria A

– Conducted immunity EN 61000-4-6, 20 Vrms, perf. criteria A

– Magnetic field immunity EN 61000-4-8, 30 A/m, perf. criteria A

– Voltage dip and interruptions EN 61000-4-11, 1 cycle perf. criteria A,

250 cycle perf. criteria B

Safety standards and certification UL/IEC/EN 60950-1, UL/IEC/EN 62368-1

UL/IEC/EN 60601-1 3rd edition

Protection class class II prepared

Connection PCB mount

38.1 (1.50)

Bottom view

35.05 (1.38)

25.4 (1.0)

16.24 (0.64)

6.12

1.5 (0.06)

4.5 (0.18)

Pin Single

4

–Vout

5

+Vout
