TPP 65A Series, 65 Watt

www.tracopower.com Page 2 of 3

All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.

Input Specifications

Input voltage range – AC range (universal input) 85 – 264 VAC

– DC range 120 – 370 VDC

Input frequency 47 – 63 Hz

Input current at full load – at 115 VAC / 230 VAC 1.65 A max. / 0.95 A max.

Input protection T3.15 A/250 VAC

(internal fuse in both line & neutral)

other models: 0.5% max.

Regulation - multi output – Input variation 0.2% max.

– Load variation (0 - 100%) 0.5% max.

Minimum load not required

Temperature coefficient 0.02 %/K max.

Hold-up time – Vin = 115 VAC 16 ms typ.

Start-up time <1 s

Rise time 20 ms typ.

Ripple and noise 5 &12 VDC models: 75 mVp-p typ.

w. cap. 10µF/25V 1206 X7R MLCC

(20 MHz bandwidth) 24 VDC models: 75 mVp-p typ.

w. cap. 1µF/50V 1206 X7R MLCC

12 VDC model: 4520 µF max.

24 VDC model: 1130 µF max.

48 VDC model: 285 µF max.

General Specifications

Operating temperature –40°C to +85°C

with derating

Output power derating – at 230 VAC 2 %/K above +60°C

– at 115 VAC 2 %/K above +55°C

Storage temperature –40°C to +85°C

Isolation resistance (at 500 VDC) 100 MOhm min.

Reliability – calculated MTBF at +25°C acc. to IEC 61709 1‘500‘000 h for single output models

1‘000‘000 h for multi output models

Protection class class II prepared
