Planet SW-504 [6/16] Product features
![Planet SW-504 [6/16] Product features](/views2/1070882/page6/bg6.png)
6
1.3 Product Features
● Comply with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
● 5/8-Port 10/100Mbps Auto-Negotiation ports - 10/20Mbps (Half-
duplex), 100/200Mbps (Full-duplex) Auto-sensing
● Compact size design for wall mount or desktop placement
● High performance Store-and-Forward Switching Architecture
● Runt and CRC ltering
● Flow control (Back Pressure) supports in half-duplex mode
● 1K MAC Address Table, automatically learning and aging
● LED indicators array for easy diagnostic, troubleshooting
● Plug-and-Play Installation
● Auto-MDI/MDIX on each port
● FCC Part 15 Class B, CE
