4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Socket 1151 for 8th Intel® Core i7 / i5 / i3 / Penum / Celeron processor
Maximum CPU TDP (Thermal Design Power): 95Wa
* 8th Generaon Intel® Core™ Processor Family only support 300-Series.
* Please refer to www.biostar.com.tw for CPU support list.
Chipset
H310MHD PRO: INTEL® H310
B360MHD PRO / B360MHD PRO2: INTEL® B360
Memory
Supports Dual Channel DDR4 1866/2133/2400/2666
2x DDR4 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 4/8/16GB DDR4 module
* Please refer to www.biostar.com.tw for Memory support list.
Storage
4x SATA III Connector
B360MHD PRO2: 1x M.2 (32Gb/s) - Supports PCI-E & SATA SSD
LAN
RTL8111H
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC887
7.1 Channels, High Denion Audio
USB
H310MHD PRO:
4x USB 3.1(Gen1) port (2 on rear I/Os and 2 via
internal header)
6x USB 2.0 port (4 on rear I/Os and 2 via internal
header)
B360MHD PRO / B360MHD PRO2:
6x USB 3.1(Gen1) port (4 on rear I/Os and 2 via
internal header)
6x USB 2.0 port (2 on rear I/Os and 4 via internal
header)
Expansion Slots
H310MHD PRO:
2x PCIe 2.0 x1 Slot
1x PCIe 3.0 x16 Slot
B360MHD PRO / B360MHD PRO2:
2x PCIe 3.0 x1 Slot
1x PCIe 3.0 x16 Slot
Rear I/Os
H310MHD PRO:
1x PS/2 Mouse
1x PS/2 Keyboard
1x HDMI Port
1x DVI-D Port
1x VGA Port
1x LAN Port
4x USB 2.0 Port
2x USB 3.1(Gen1) Port
3x Audio Jack
B360MHD PRO / B360MHD PRO2:
1x PS/2 Mouse
1x PS/2 Keyboard
1x HDMI Port
1x DVI-D Port
1x VGA Port
1x LAN Port
2x USB 2.0 Port
4x USB 3.1(Gen1) Port
3x Audio Jack
Internal I/Os
H310MHD PRO:
4x SATA III Connector
1x USB 2.0 Header (each header supports 2 USB 2.0
ports)
1x USB 3.1(Gen1) Header (each header supports 2
USB 3.1(Gen1) ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x COM Port Header
B360MHD PRO / B360MHD PRO2:
4x SATA III Connector
2x USB 2.0 Header (each header supports 2 USB 2.0
ports)
1x USB 3.1(Gen1) Header (each header supports 2
USB 3.1(Gen1) ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x COM Port Header
Form Factor uATX Form Factor, 228mm x 177mm
OS Support
Windows 10(64bit)
* Biostar reserves the right to add or remove support for any OS with or without noce.
