APPENDIX I: Specicaons in Other Languages | 31
TB250-BTC PRO / TB250-BTC+
German
Spezikaonen
CPU-Unterstützung
Anschluss-1151 für Intel® Core i7 / i5 / i3 / Penum / Celeron Prozessor
Maximale CPU TDP (Thermal Design Power): 95 Wa
* Bie konsuleren Sie www.biostar.com.tw für CPU-Unterstützungsliste
Chipset INTEL® B250
Festplaenspeicher
Unterstützt zweikanaliges DDR4 1866/2133/2400
2x DDR4 DIMM-SpeicherSlot, Max. Uterstützung bis zu 32 GB-Speicher
Jedes DIMM unterstützt nicht-ECC 4/8/16 GB DDR4-Module
*
DDR4-2400 für die Intel® Core ™ Prozessorfamilie der 7. Generaon.
*
Bie konsuleren Sie www.biostar.com.tw für für Speicherunterstützung Liste.
Arbeitsspeicher 6x SATA III-Verbindung (6Gb/s)
LAN
RTL8111H
10/ 100/ 1000 Mb Auto-Negoaon, Halb- / Voll-Duplex-fähig
Audio-Codec
ALC887
7.1 Kanäle, HD-Audio
USB
6x USB 3.0-Port (4 hintere I/Os und 2 via interne Header)
6x USB 2.0-Port (2 hintere I/Os und 4 via interne Header)
Erweiterungsanschlüsse
TB250-BTC PRO:
11x PCIe 3.0 x1-Slot
1x PCIe 3.0 x16-Slot
TB250-BTC+ :
7x PCIe 3.0 x1-Slot
1x PCIe 3.0 x16-Slot
* PCIe 3.0 x1-Slot : Für Crypto Mining, ändern Sie die Geschwindigkeit auf PCI-E 2.0 in BIOS-Einstellung
* Maximale VGA-Karten Bergbau-Unterstützung sind abhängig von VGA-Treiber oder Bergbau-
Soware.
Hintere I/Os
1x PS/2-Maus
1x PS/2-Keyboard
1x DVI-D-Port
1x LAN-Port
2x USB-Port (Nur 1,5 A Leistung)
2x USB 2.0-Port
4x USB 3.0-Port
3x Audio Jack
Interne I/Os
6x SATA III-Verbindung (6Gb/s)
2x USB 2.0-Header (jeder Header unterstützt 2 USB 2.0-Ports)
1x USB 3.0-Header (jeder Header unterstützt 2 USB 3.0-Ports)
1x 8-Pin-Stromverbindung
1x 24-Pin-Stromverbindung
2x 4-Pin-Stromverbindung (Für Crypto Mining, 4pin Stromanschluss Muss installiert sein)
1x 15-poliger SATA-Stromanschluss (Für USB-Leistungserhöhung)
1x CPU-Venlatorverbindung
2x System-Venlatorverbindung
1x Header für Frontpanel
1x Header für Frontaudio
1x Header für Seriellen Anschluss
1x Header für klares CMOS
Formfaktor ATX Formfaktor, 295 mm x 210mm
OS-Unterstützung
Windows 7 (32/64bit)/ 8.1(64bit) /10(64bit)
*
Windows 7 (32/64 Bit) / 8.1 (64 Bit) für die Intel® Core ™ Prozessorfamilie der 6. Generaon.
*
Biostar reserves the right to add or remove support for any OS with or without noce.
