4 | Chapter 1: Introducon
1�3 Specicaons
Specicaons
CPU Support
Socket 1151 for Intel® Core i7 / i5 / i3 / Penum / Celeron processor
Maximum CPU TDP (Thermal Design Power): 91Wa
* Please refer to www.biostar.com.tw for CPU support list.
Chipset INTEL® H110
Memory
Supports Dual Channel DDR3L 1866(OC)/1600/1333
2x DDR3L DIMM Memory Slot, Max. Supports up to 16 GB Memory
Each DIMM supports non-ECC 4/8 GB DDR3L module
* Please refer to www.biostar.com.tw for Memory support list.
Storage
4x SATA III Connector
supports AHCI
LAN
RTL8111H (H110MHV3, H110MGV3)
1x 10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
RTL8106E (H110MLV3)
1x 10/ 100 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC887
7.1 Channels, High Denion Audio
USB
4x USB 3.0 port (2 on rear I/Os and 2 via internal header)
6x USB 2.0 port (2 on rear I/Os and 4 via internal header)
Expansion Slots
1x PCIe 2.0 x1 Slot
1x PCIe 3.0 x16 Slot (x16)
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x HDMI Port (H110MHV3)
1x VGA Port
1x LAN port
2x USB 2.0 Port
2x USB 3.0 Port
3x Audio Jack
Internal I/Os
4x SATA III Connector
2x USB 2.0 Header
1x USB 3.0 Header
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x TPM Header
Form Factor uATX Form Factor, 170mm x 190mm
OS Support
Windows 7/ 8.1(64bit)/ 10(64bit)
Biostar reserves the right to add or remove support for any OS with or without noce.
