TZ77B/TZ75B/T77
59
СПЕЦ
Входной звуковой разъём x1
Поддержка звуко вых функций на лицевой
панели
Контактирующее приспособление
вентилятора центрального процессора x1
Источник питания для вентилятора центрального
процессора (с функцией интеллектуального
вентилятора)
Контактирующее приспособление
вентилятора системы x2
Источник питания для вентилятора системы
Открытое контактирующее
приспособление CMOS x1
USB2.0-разъём x2
Каждый разъём поддерживает 2 USB2.0-порта на
лицевой панели
USB3.0-разъём x1
Каждый разъём поддерживает 2 USB3.0-порта на
лицевой панели
Разъём едока ИКЫЙ x1
Последовательный порт x1
Разъём вывода для S/PDIF x1 Поддержка вывода цифровой звуковой фун кции
Разъем питания (24 вывод) x1
Разъем питания (8 вывод) x1
Задняя
панель
средств
ввода-выв
ода
Клавиатура PS/2 x1
Порт HDMI x1
Порт VGA x1
Порт DVI x1
Порт LAN x1
USB2.0-порт x4
USB3.0-порт x2
Гнездо для подключения
наушников x6
Размер
панели
220 мм (Ш) X 295 мм (В) ATX
Поддержка
OS
Windows XP / Vista / 7
Biostar сохраняет за собой право добавлять или
удалять средства обеспечения для OS с или без
предварительного уведомления.
