TZ77B/TZ75B/T77
5
1.5 MOTHERBOARD LAYOUT
USB_KBMS1
HDMI1
DVI1
VGA1
USB3_0
RJ45USB1
AUDIO1
ATXPWR2
CODEC
F_AUDIO1
SYS_FAN2
JSPDIFOUT1
Super
I/O
JFRONT_USB3_1
J_COM1
CIR1
PEX1_2
PEX16_1
PEX16_2
PEX1_1
PCI1
PCI2
F_USB1F_USB2
SYS_FAN1
PAN EL1
SW_PWR1
SW_RST1
BAT1
LAN
Intel
Z77/Z75
H77
BIOS
JCMOS1
SATA2
SATA4
SATA1
SATA3
SATA6 SATA5
ATXPWR1
DDR3 _A1
DDR3 _A2
DB2DR3 _
DDR3 _B1
CPU_FAN1
Socket 1155
CPU1
Note: represents the 1■
st
pin.
