Motherboard Manual
52
SPANISH
Especificación
CPU
Socket 1155
Proces ador Intel Cor e i7 / i5 / i3 / Pent iu m /
Celeron
Admite Bit de deshabilitación de ejecución / Intel
SpeedStep® Mejorado / Int el Architecture-64 /
Tecno log ía Extended Memory 64 / Tecno logía de
virtualización / Hyper Threading
Conjunto de
chips
Intel Z77 (TZ77A)
Intel Z75 (TZ75A)
Súper E/S
IT8728
Le ofrece las funcionalidades heredadas de
uso más común Súper E /S.
Interfaz de cuenta Low Pin
In ic iat ivas de control d e entorno,
Monitor hardware
Controlador/monitor de velocidad de ventilador
Función "Guardia inteligente" de ITE
Memoria
principal
Ranuras DIMM DDR3 x 4
Capacidad máxima de memoria de 32GB
Cada DIMM admite DDR de
512MB/1GB/2GB/4GB/8GB
Módulo de memoria DDR3 de canal Doble
Admite DDR3 de 1066 / 1333
Admite DDR3 de 1600 / 1866(OC) / 2133(OC)
No admite DIMM registrados o DIMM compatibles
con ECC
SATA 2 & 3 Controlador ATA Serie Integrado
Tasas de transferencia de hasta 3.0 Gb/s / 6.0 Gb/s.
Compat ib le con la versión SATA 2.0 / 3.0 .
Admite RAID 0,1,5,10, SRT (TZ77A)
Red Local Realtek RTL 8111E
Negociación de 10 / 100 / 1000 Mb/s
Funciones Half / Full dúplex
Soporte de
sonido HD
ALC892
Soporte de sonido de Alta Definición
Salida de sonido de 7.1 canales
USB3.0
Z77 (TZ77A) / Z75 (TZ75A) Tasas de transferencia de datos hasta 600 MB / s
Ranura PCI X2
Ranura PCI Express Gen3 x16 X1
Ranura PCI Express Gen2 x16(x4) X1
Ranuras
Ranura PCI Express Gen2 x 1 X2
Conector SATA3 X2 Cada conector soporta 1 dispositivos SATA3
Conector SATA2 X4 Cada conector soporta 1 dispositivos SATA2
Conector de p ane l frontal X1 Soporta instalaciones en el p anel frontal
Conector de sonido frontal X1 Soporta funciones de sonido en el panel frontal
Cabecera de ventilador de CPU X1 Fuente de alimentación de ventilador de CPU (con
función Smart Fan)
Conectores
en placa
Cabecera de ventilador de sistema X2 Fuente de alimentación de ventilador de sistema
