TH67+/TH67/TH67B
49
TH67+ / TH67 TH67B
Porta série x1 Porta série x1
Conector SATA 3 x2 Conector SATA 3 x2
Conector SATA 2 x4 Conector SATA 2 x4
Conector do painel frontal x1 Conector do painel frontal x1
Conector de áudio frontal x1 Conector de áudio frontal x1
Conector de saída S/PDIF x1 Conector de saída S/PDIF x1
Conector da ventoinha da CPU x1 Conector da ventoinha da CPU x1
Conector da ventoinha do sistema x2 Conector da ventoinha do s istema x2
Conector para limpeza do CMOS x1 Conector para limpeza do CMOS x1
Conector USB 2.0 x3 Conector USB 2.0 x3
Conector de IR do consumidor x1 Conector de IR do consumidor x1
Conector de alimentação x1
(24 pinos)
Conector de alimentação x1
(24 pinos)
Conectores
na placa
Conector de alimentação x1
(8 p inos)
Conector de alimentação x1
(4 p inos)
Entradas/Saí
das no painel
traseiro
Teclado / Rato PS/2 x1
Porta HDMI x1
Porta VGA x1
Porta DVI-D x1
Porta LAN x1
Porta USB 2.0 (por H67) x2
Porta USB 3.0 (por NEC uPD720200 /
Asmedia ASM1042) x2
Tomada de áudio x3
Teclado / Rato PS/2 x1
Porta HDMI x1
Porta VGA x1
Porta DVI-D x1
Porta LAN x1
Porta USB 2.0 x4
Tomada de áudio x3
Tamanho da
placa
230mm (L) X 244 mm (A) 230mm (L) X 244 mm (A)
Sistemas
operativos
suportados
Windows XP / Vista / 7
A Biostar reserva-se o direito de adicionar ou
remover suporte para qualquer sistema
operativo com ou sem aviso prévio.
Windows XP / Vista / 7
A Biostar reserva-se o direito de adicionar ou
remover suporte para qualquer sistema
operativo com ou sem aviso prévio.
