http://www.tracopower.com Page 1 of 5

Industrial Power Supplies TBLC Series, 6 – 90 W

• Low proﬁle case, module depth only

59,5mm

• Suitable for mounting in domestic

installation panels

• Low output ripples and spikes

• Fully compliance to ECO-Standard

• Suitable for houshold appliance

• Safety class ll product

• UL 1310 class II, NEC class 2

compliance

• UL 508 listed

• Universal input range 85 to 264 VAC

• Operating temperature range:

–25°C to +70°C max.

• Adjustable output voltage

Short circuit and overload protection

• DC–OK indicator

This new DIN-Rail mounting power supplies are designed for industrial and resi-

dential applications. They are lower cost than the existing TBL range, with similar

electrical speciﬁcations. Additionally, they fully comply to the new standby power

and efﬁciency requirements (ECO Standard). They are intended for connect-

ing as class II devices, so the safety earth connection is not required. They are

mountable in ﬂat racks due to their small dimensions in depth. Their dimensions

comply to the DIN 43 880 standard.

Order Code Output Power

(max.)

Output Voltage*

(nom.)(adjustable)

Output Current

(max.)

Efﬁciency

(typ.)

TBLC 06-105 6 W

5.0 VDC 1.2 A 74 %

TBLC 06-112 6 W

12 VDC 0.5 A 81 %

TBLC 06-124 6 W

24 VDC 0.25 A 79 %

TBLC 15-105 12 W

5.0 VDC 2.4 A 81 %

TBLC 15-112 15 W

12 VDC 1.25 A 85 %

TBLC 15-124 15 W

24 VDC 0.63 A 85 %

TBLC 25-105 20 W

5.0 VDC 4.0 A 82 %

TBLC 25-112 24 W

12 VDC 2.0 A 86 %

TBLC 25-124 25 W

24 VDC 1.05 A 87 %

TBLC 50-112 48 W

12 VDC 4.0 A 88 %

TBLC 50-124 50 W

24 VDC 2.1 A 89 %

TBLC 75-112 72 W

12 VDC 6.0 A 89 %

TBLC 75-124 75 W

24 VDC 3.1 A 89 %

TBLC 90-112 90 W

12 VDC 7.5 A 90 %

TBLC 90-124 90 W

24 VDC 3.75 A 90 %

Models

UL508

Scheme

UL60950-1

UL1310
