TBLC Series, 6 – 90 W

General Specifications (continued)

Safety standards – Information technology equipment

IEC/EN 60950-1, UL 60950-1

– Household applications IEC/EN 60335-1

– Safety of machinery EN 60204

– Safety for power electronic converter systems IEC/EN 62477

– Industrial control equipment UL 508

– Class II Power units UL 1310

– NEC class 2 UL 1310 (except TBLC 75-112 and 90-112)

– Electronic equipment for power installation EN 50178

– Safety of transformers EN 61558-2-8, EN 61558-2-16

– Certification documents (pending) www.tracopower.com/overview/tblc

Electromagnetic compatibility (EMC), Emissions EN 61000-6-3, EN 61204-3

– Conducted RI suppression on input EN 55022 class B,

– Radiated RI suppression EN 55022 class B,

– Harmonic current emissions IEC 61000-3-2 class A

Electromagnetic compatibility (EMC), Immunity EN 61000-6-2, EN 61204-3

– Electrostatic discharge (ESD) IEC/EN 61000-4-2 4 kV/8 kV criteria B

– Radiated RF field immunity IEC/EN 61000-4-3 10 V/m criteria A

– Electrical fast transient / burst immunity IEC/EN 61000-4-4 2 kV criteria B

– Surge immunity IEC/EN 61000-4-5 1 kV/2 kV criteria B

– Immunity to conducted RF disturbances IEC/EN 61000-4-6 10 V criteria A

– Power frequency field immunity IEC/EN 61000-4-8 30 A/m criteria A

– Mains voltage dips and interruptions IEC/EN 61000-4-11

0% / 20ms

40% / 200ms

70% / 500ms

Environment – Vibration acc. IEC 60068-2-6 3 axis, 2g sine sweep, 10 – 55 Hz, 11 Oct/min

– Shock acc. IEC 60068-2-27 3 axis, 20g half sine, 11 ms

Enclosure material V2 rated plastic

Mounting – DIN-rail mounting for DIN-rails as per EN 50022-3515/7.5

(snap-on with self-locking spring) (included)

Environmental compliance – Reach www.tracopower.com/products/reach-declaration.pdf

– RoHS RoHS directive 2011/65/EU

Connection screw terminal with combi-type screwheads

for wire size 0.5 – 2.5mm
