TBLC Series, 6 – 90 W

All speciﬁcations valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.

Input Specifications

Input voltage – nominal ranges 100 – 240 VAC; 50/60 Hz

– effective ranges 85 – 264 VAC; 47-63 Hz

(below 100 VAC a derating of 2%/V is required)

Input voltage frequency 47 – 63 Hz

No load power consumption 6–50 W models: > 0.3 W

75–90 W models: > 0.5 W

Harmonic limits EN 61000-3-2, class A

Leakage current 0.25 mA max.

Inrush current 6–50 W models: 15/30 A (115 / 23 0 VA C )

75–90 W models: 25/50 A (115 /23 0 VA C )

Output Specifications

Output voltage / current 5 VDC models: 5.0 – 5.5 VDC*

12 VDC models: 12.0 – 16.0 VDC*

24 VDC models: 24.0 – 28.0 VDC*

Regulation – Input variation 0.3 % max.

– Load variation (10–90 %) 0.3 % max.

Hold-up time 60 ms min. (at 230 VAC)

15 ms typ. (at 115 VAC)

Start-up – Start up behaviour TBLC 075-112 and 090-112: 0-75 % constant current load

other models: 0-100 % constant current load

– Start up time 1 s max.

Ripple and Noise (20MHz bandwidth) 50 mVp-p max.

Current limit (continuous) 105 – 130 % of Iout nom., constant current

Short circuit current 70 – 200 % of Iout nom. (typ.), foldback

Output overvoltage protection 150 % of Vout nom. (typ.)

DC OK signal – trigger threshold ON > 95 % of the set voltage

General Specifications

Operating temperature –25°C to +70°C max.

derating above +55ºC : 2.5%/K

Storage temperature –40°C to +85°C max.

Temperature coefficient 0.02 %/K

Cooling convection cooling, no internal fan

Pollution degree 2

Humidity (non condensing) 5–95 % rel. H max.

Altitude during operation 4800 m max.

Isolation – I/O isolation 3000 VAC (4242 VDC)

Class of protection safety class II

Degree of protection IP 20 (IEC/EN 60529)

* Output voltage can be adjusted as indicated. However, output power has to be maintained at nominal value. This means the output

nominal current has to be reduced in accordance with the increase of output voltage.
