Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket 1155
Intel Core i7 / i5 / i3 / Pent ium / C e leron
processor
Supports Execute Disable B it / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization Technology /
Hyp er Thread ing
Chipset
Intel H61
Super I/O
IT8728
Provid ing the most common ly used leg acy
Super I/O functionality
Low Pin Count Interface
Environment Control init iatives
Hardware Monitor Controller
Fan Sp eed Contro ller
ITE's "S mart Guard ian" function
Main
Memory
DDR3 DIMM Slots x 2
Max Memory Capacity 16GB
Each DIMM supports 512MB/
1GB/2GB/4GB/8GB DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 1066 / 1333
Registered DIMM and ECC D IMM is not supported
SATA 2
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s
SATA Version 2.0 specificat ion co mp liant
LAN
Realtek RTL8111E
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
Codec
ALC892
7.1 channels audio out
High Definition Audio
USB3.0
Asmedia ASM1042 Data transfer rates up to 600 MB/s
Slots
PCI Express Gen2 x16 Slot x1 Supports PCI-E Gen2 x16 expansion card
SATA2 Connector x4 Each connector supports 1 SATA2 device
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
CPU Fan Header x1 CPU Fan power supply (with Smart Fan function)
System Fan Header x1 System Fan Power supply
Clear C MOS Header x1 Restore CMOS dat a to factory default
On Board
Connectors
USB2.0 Connector x1 Each connector supports 2 front panel USB2.0 ports
