TRACO POWER TIB 080-112 [4/6] Tib 080 series 80 watt

Clearance

- Input to Output

8 mm min.

- Input to Case or PE

4 mm min.

- Output to Case or PE

1.5 mm min.

Leakage Current

- Earth Leakage Current

3500 µA max.

- Touch Current

310 µA max.

Reliability

- Calculated MTBF

1'950'000 h (IEC 61709)

Environment

- Vibration

EN 61373

IEC 60068-2-6

3 axis, sine sweep, 10 - 55 Hz, 2 g, 11 oct/min

- Mechanical Shock

EN 61373

IEC 60068-2-27

3 axis, 25 g half sine, 11 ms shock

Housing Material

Aluminium (Chassis)

Stainless Steel (Cover)

Connection Type

Screw Terminal

Mounting

- DIN Rail

For DIN-rails as per EN 50022-35×15/7.5

Weight

367 g

Thermal Impedance

1.81 K/W

Power Back Immunity

12 VDC model:

19 V max.

24 VDC model:

35 V max.

48 VDC model:

60 V max.

When external voltage is supplied above set out-

put voltage and below OVP threshold, the power

supply will function normally without switch off or

destruction, even if external voltage is applied

continuously.

Power OK Signal

Relay Output

- Trigger Threshold

12 VDC model:

OK: 10.9 VDC, Off: 10.7 VDC

24 VDC model:

OK: 22.5 VDC, Off: 21.5 VDC

48 VDC model:

OK: 45 VDC, Off: 43 VDC

- Power OK

Relay contact closed

- Power Off

Relay contact open

- Pin Specifications

30 VDC / 1 A max.

Status Indicator

Also indicated by green LEDs: front and side

Environmental Compliance

- Reach

www.tracopower.com/info/reach-declaration.pdf

- RoHS

www.tracopower.com/info/rohs-declaration.pdf

Supporting Documents

Overview Link (for additional Documents)

www.tracopower.com/overview/tib080

TIB 080 Series, 80 Watt

All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.

www.tracopower.com

April 9, 2019

Page 4 / 6
