TRACO POWER TIB 240-124EX [5/6] Tib 240 ex series 240 watt
![TRACO POWER TIB 240-124EX [5/6] Tib 240 ex series 240 watt](/views2/1709213/page5/bg5.png)
Blockdiagram
Outline Dimensions
TIB 240-EX Series, 240 Watt
All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.
www.tracopower.com
April 9, 2019
Page 5 / 6
Model
Ind ustria l Power S upp ly
240 W
V ad j.
24 VDC/10 A
100-240 VAC, 50-60 Hz
2.89-1.27 A
DC
ON
DC OK
L N
TIB 240-124
* Measurement from fron panel to DIN-Rail
118,6 ±1*
114,2 ±1
48 ±1
6,35
M3
Combi Head
9,5
M3
Combi Head
124,2 ±1
DIN-Rail
Hook
