www.tracopower.com Page 2 of 6
All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.
Battery Controller Module
TSP-BCM Series 72–600 Watt
Output Specifications
Ouput Voltage range – TSP–BCM12 12-14 VDC
(adjustable with potentiometer) – TSP–BCM24 & TSP–BCM24A 24-28 VDC
– TSP–BCM48 & TSP–BCM48A 48-56 VDC
Ripple and noise (20 MHz bandwidth) 200 mVp-p max.
Capacitive load unlimited
General Specifications
Operating temperature –25°C to +70°C max.
– TSP–BCM24 & TSP–BCM24A derating above +40°C : 1.5 %/K
– other models derating above +40°C : 1.67 %/K
Storage temperature –25°C to +85°C max.
Temperature coefficient 0.02 %/K
Humidity (non condensing) 95 % rel. H max.
Reliability, calculated MTBF at +25°C acc. to IEC 61709 > 1.5 Mio. h
Battery protection against over voltage, deep discharge, overcharge,
short circuit and reverse connection (built-in fuse)
Status signals DC OK input, DC OK output, BAT OK
all relay contact closed at status OK
Rating per relay contact 30 VDC / 0.6A or 60 VDC / 0.3A
Polution degree 2
Remote On/Off by ext. contact: contact open = On, contact closed = Off
Remote link cable (0.5 m) 2 cables included (order code TSP-JC)
www.tracopower.com/products/tsp-rc-cable.pdf
Degree of protection IP 20 (IEC/EN 60529)
Altitude during operation tba.
Safety standard IEC/EN 60950-1, UL 60950-, UL508
IEC/EN 61010-1, IEC/EN 61010-2-201
Safety approvals – CSA UL 60950, UL 508
– CB test certificate IEC 60950-1 (SIQ for EN)
IEC/EN 61010-1, IEC 61010-2-201
– Certfication documents www.tracopower.com/overview/tsp
Electromagnetic compatibility in correspondence to connected units
(no internal switching device)
Environment – Vibration acc. IEC 60068-2-6; 3 axis, sine sweep, 10 – 55 Hz, 1 g, 1 oct/min
– Shock acc. IEC 60068-2-27 3 axis, 15 g half sine, 11 ms
Enclosure material aluminium (chassis) / stainless steel (cover)
Mounting – DIN-rail mounting for DIN-rails as per EN 50022-35x15/7.5
(snap-on with self-locking spring)
– Wall mounting (option) with wall mounting bracket - see page 4
Connection detachable screw terminals (plugs included)
2 terminals per output
Installation instructions www.tracopower.com/overview/tsp
Input Specifications
Input current limitation – TSP–BCM12 10.5 A
(factory setting) – TSP–BCM24 12.8 A
– TSP–BCM48 6.4 A
– TSP–BCM24A 10.7 A
– TSP–BCM48A 6.4 A
