H61MGV3/H61MLV3
29
SPEC
Embase de ventilateur système x1 Alimentation électrique du ventilateur système
Châssis Connecteur Haut-parleur x1
Embase d'effacement CMOS x1
Connecteur USB2.0 x2
Chaque connecteur prend en charge 2 ports USB2.0
de panneau avant
Port série x1
Connecteur d'alimentation x1
(24 broches)
Connecteur d'alimentation x1
(4 broches)
E/S du
panneau
arrière
Clavier PS/2 x1
Souris PS/2 x1
Port VGA x1
Port LAN x1
Port USB2.0 x4
Fiche audio x3
Dimensions
de la carte
170 mm (l) X 191 mm (H)
Support SE
Windows XP / Vista / 7 / 8
Biostar se réserve le droit d'ajouter ou de supprimer
le support de SE avec ou sans préavis
