Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket 1155
Intel Core i7 / i5 / i3 / Pentium / Celeron
processor
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization Technology /
Hyper Threading
Chipset Intel H61
Super I/O
IT8772E
Provides the most commonly used legacy
Super I/O functionality
Low Pin Count Interface
Environment Control initiatives
Hardware Monitor Controller
Fan Speed Controller
ITE's "Smart Guardian" function
Main
Memory
DDR3 DIMM Slots x 2
Max Memory Capacity 16GB
Each DIMM supports 512MB/
1GB/2GB/4GB/8GB DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 1066 / 1333
Supports DDR3 1600 (depending on CPU)
Registered DIMM and ECC DIMM is not supported
SATA 2 Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s
SATA Version 2.0 specification compliant
LAN
RTL8111G (H61MGV3)
RTL8106E (H61MLV3)
10 / 100 / 1000Mb/s auto negotiation
10 / 100 Mb/s auto negotiation
Sound
Codec
VT1705CF / ALC662 5.1 channels audio out , High Definition Audio
PCI-E Gen3x16 slot x1
(depending on CPU)
Supports PCI-E Gen2/3 x16 expansion card
Slots
PCI-E Gen2 x1 slot x1 Supports PCI-E Gen2 x1 expansion card
SATA2 Connector x4 Each connector supports 1 SATA2 device
Front Panel Connector x1 Supports front panel facilities
Chassis Speaker Connector x1 Supports chassis speaker
Front Audio Connector x1 Supports front panel audio function
CPU Fan Header x1 CPU Fan power supply (with Smart Fan function)
System Fan Header x1 System Fan Power supply
Clear CMOS Header x1 Restore CMOS data to factory default
USB2.0 Connector x2 Each connector supports 2 front panel USB2.0 ports
Serial Port Connector x1 Connects to RS-232 Port
Power Connector (24pin) x1 Connects to Power supply
On Board
Connectors
Power Connector (4pin) x1 Connects to Power supply
Rear Panel
I/O
PS/2 Keyboard x1
PS/2 Mouse x1
VGA Port x1
LAN port x1
USB2.0 Port x4
Audio Jack x3
Connects to PS/2 Keyboard
Connects to PS/2 Mouse
Connect to D-SUB monitor
Connect to RJ-45 Ethernet cable
Connect to USB2.0 devices
Provide Audio-In/Out and Mic. Connection
Board Size 170 (W) x 191 (L) mm
OS Support Windows XP / Vista / 7 / 8
Biostar reserves the right to add or remove support
for any OS with or without notice
