![Planet ICA-510 [9/28] Physical installation](/views2/1070958/page9/bg9.png)
9
Port Description
AUDIO IN An external microphone can be plugged in.
AUDIO OUT An external speaker can be plugged in.
RESET
Reset to manufacturer default valued and reboot.
When pressed and held over 10 seconds, the settings
of IP Camera will be set to the default values.
DC 12V
Connect the supplied power adapter.
When this device is obtaining power from PoE, you
don’t have to attach the power adapter.
LAN (PoE)
Connect your Camera to a 10/100Base-TX hub or
switch. It is compliant with IEEE 802.3af PoE. Either
mid-span PSE or end-span PSE supported.
3.3 Physical Installation
1. Connect an Ethernet cable
Connect one end of an Ethernet cable to the LAN port located on
the IP camera’s rear panel and connect the other end to the network
device (hub or switch).
2. Attach the external power supply
Attach the provided power adapter to the IP camera’s connector
labeled “DC 12V” on the rear panel. If this camera is obtained power
from PoE, you don’t have to attach the power adapter.
Note
Please use the power adapter that is bundled in package.
Using a power supply with a different voltage rating will
damage and void the warranty for this product.
3. Connect Microphone and Speaker
If you will use the 2-Way audio function, please connect microphone
to Audio In and speaker to Audio Out.
