3.5.4 Streaming
RTSP is a streaming control protocol, and a starting point for negotiating transports such as RTP,
multicast and Unicast, and for negotiating codecs. RTSP can be considered a "remote control" for
controlling the media stream delivered by a media server. RTSP servers typically use RTP as the
protocol for the actual transport of audio/video data.
RTSP Port Choose the RTSP port. The RTSP protocol allows a connecting client to start a
video stream. Enter the RTSP port number to use. The default value is 554.
RTP Port Specify the range of transmission port number of video stream. The default range
is 50000 to 50999. User can specify a number between 1024 and 65535.
To use the 3GPP function, in addition to previous section, you might need more information or
configuration to make this function work.
NOTE: To use the 3GPP function, it strongly recommends installing the Networked Device with
a public and fixed IP address without any firewall protection.
RTSP Port Port 554 is the default for RTSP service. However, sometimes, some service
providers change this port number for some reasons. If so, user needs to change
this port accordingly.
Dialing procedure
1. Choose a verified player (PacketVideo or Realplayer currently)
2. Use the following URL to access: rtsp://host/mpeg4/media.3gp
Where host is the host name or IP address of the camera.
Compatible 3G mobile phone Please contact your dealer to get the approved list of
compatible 3G phone.
40
