Case 2: (Peer-to-Peer mode) VIP-157S Port 1 to Port 2 communications

Supposing one VIP-157S connects to two telephones, just pick up phone 1 and dial

‘192*168*0*1**5062’, phone 2 will ring.

Analog telephone sets are connected to the phone (RJ-11) ports of VIP-157S respectively

192.168.0.1

1001

1002

Test the scenario:

1. Pick up the telephone set on VIP-157S port 1, and you should be able to hear the dial-tone

2. Press the keypad: 192*168*0*1**5062# shall be able to connect to the VIP-157S port 2

3. Then the telephone set in VIP-157S port 2 should ring. Please repeat the same dialing steps on

port 2 to establish the first voice communication from VIP-157S

1 9 2

* 1 6 8 * 1

** 0 0 6 5 2 #

y If the IP address of the remote calling party is known,

you may directly make calls via its IP address and end

with a “#”.

y If the ATAs are installed behind a NAT/firewall/IP

sharing device for Peer-to-Peer VoIP application,

please make sure the NAT device support SIP

applications, and suitable settings should be applied

to the NAT device to enable the SIP communications

before making calls

y [VIP-157S] in PLANET ATA series products, to connect

to remote ATA, press the keypad in the following

sequence to connect to the remote VIP-157S port 2:

[remote ATA IP address]**5062, for example:

192*168*0*2**5062
