6
Chapter 1
1
Introduction
Overview
Based on years of VoIP manufacturing experiences, PLANET Technology VoIP total solutions are
known for advanced implementation of standards based telephony with mass deployment capability.
Cost-effective, easy-to-install and simple-to-use, the PLANET VIP-156/VIP-157/VIP-157S VoIP Phone
Adapter (“ATA” in the following term) converts standard telephones to IP-based networks. The service
providers and enterprises offer users traditional and enhanced the telephony communication services
via the existing broadband connection to the Internet or corporation network.
With the ATA, home users and companies are able to save the installation cost and extend their past
investments in telephones, conference and speakerphones. The ATA can be the bridge between
traditional analog systems and IP network with an extremely affordable investment.
The ATA includes two alternatively Ethernet interface for Internet (PPPoE, DHCP or Fixed IP), or office
LAN connection. With adding the auto-provision feature of our IP PBX product - IPX-2000, the ATA can
be seamlessly integrated into the telephony network and be used in consumer and business IP
telephony service, no expertise required!
The ATA and our IP PBX system integration are the ideal combination for your office daily
communications.
Product Features
• Feature-rich telephone service over home or office Internet/Intranet connection
• Auto-config feature for flexible, ease-of-use IP PBX system integration
• Cost effective, field proven compatibility, and stability
• Web-based and telephone keypad machine configuration
• Remote machine administration authentication
• Voice prompt for machine configurations
VoIP Features
• SIP 2.0 (RFC3261) compliant
• Peer-to-Peer / SIP proxy calls
• Voice codec support: G.711, G.723.1, G.729A/G.729B
• T.38 FAX transmission over IP network
