English 6
6-3 ADJUSTING THE AIR FLOW DIRECTION
(Refer to figure 6) (only for Double-flow,
Multi-flow, Corner, Ceiling-suspended
and Wall-mounted)
Press the air flow direction button to
select the air direction.
The air flow flap display swings as
shown below and the air flow direc-
tion continuously varies. (Automatic
swing setting)
Press the air flow direction adjust but-
ton to select the air direction of your
choice.
The air flow flap display stops swing-
ingandtheairflowdirectionisfixed.
(Fixed air flow direction setting)
MOVEMENT OF THE AIR FLOW FLAP
(Refer to figure 13)
For the following conditions, a micro computer con-
trols the air flow direction which may be different
from the display.
The air flow direction can be adjusted in one of the
following ways.
• The air flow flap itself adjusts its position.
• The air flow direction can be fixed by the user.
• Automatic “ ” and desired position “ ”.
NOTE
• The movable limit of the flap is changeable.
Contact your Daikin dealer for details. (Only
for Double-flow, Multi-flow, Corner, Ceiling-
suspended and Wall-mounted.)
•
Avoid operating in the horizontal direction
“”
. It may cause dew or dust to settle on
the ceiling.
6-4 PROGRAMMING START AND STOP OF
THE SYSTEM WITH TIMER
(Refer to figure 9)
•
The timer is operated in the following two ways.
Programmingthestoptime“ ”.Thesys-
tem stops operating after the set time has
elapsed.
Programming the start time “ ”. The sys-
tem starts operating after the set time has
elapsed.
• The timer can be programmed for a maxi-
mum of 72 hours.
• The start and the stop time can be simulta-
neously programmed.
Press the timer mode start/stop button several
times and select the mode on the display.
The display flashes.
• For setting the timer stop “ ”
• For setting the timer start “ ”
Press the programming time button and set
the time for stopping or starting the system.
Each time this button is pressed, the
time advances or goes backward by 1
hour.
Press the timer on/off button.
The timer setting procedure ends. The display
“ ” or “ ” changes from flashing
light to constant light.
NOTE
• When setting the timer off and on at the
same time, repeat the above procedure
(from “ ” to “ ”) once again.
• After the timer is programmed, the display
shows the remaining time.
• Press the timer on/off button once again to
cancel programming. The display vanishes.
For example: (Refer to figure 11)
When the timer is programmed to stop the sys-
tem after 3 hours and start the system after 4
hours, the system will stop after 3 hours and
start 1 hour later.
6-5 SETTING THE MASTER REMOTE CON-
TROLLER (for RXY series)
(Refer to figure 10)
• When the system is installed as shown in figure
14, it is necessary to designate one of the remote
controllers as the master remote controller.
FOR RXY SERIES (Refer to figure 14)
When one outdoor unit is connected with several
indoor units.
• Only the master remote controller can select
heating or cooling.
• The displays of slave remote controllers show
“ ” (changeover under control) and they
automatically follow the operation mode directed
by the master remote controller.
COOLING HEATING
• Whenstartingoperation.
• When the room temperature is
higher than the set temperature.
• At defrost operation.
• When operating continuously at horizontal air flow direction.
• When continuous operation with downward air flow is performed at the
time of cooling with a ceiling-suspended or a wall-mounted unit, the
microcomputer may control the flow direction, and then the remote control
indication also will change.
1
2
1
2
3
1 3
01_3P114261-3M_EN.fm Page 6 Thursday, November 6, 2003 7:23 PM
