Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
USBKB1
HDMI1
VGA1
DVI1
RJ45USB1
AUDIO1
JUSBV1
ATXPWR2
LAN
CODEC
F_AUDIO1 J_COM1J_PRINT1
Super
I/O
PCI1
PCI2
JSPDIFOUT1
PEX1_1
PEX16_1
JUSBV2
CIR1 F_USB2 F_USB1 PANEL1
SYS_FAN1
JCMOS1
BIOS
SATA2
SATA4
SATA1
SATA3
ID E 1
AT X PW R 1
DDR3_B1
DDR3_A1
CPU_FAN1
BAT1
H55
Socket 1156
CPU1
Note: ■ represents the 1
st
pin.
