TH55 HD BIOS Manual
17
Onboard PCI/PCI-E Devices Configuration
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 198 5-200x, American Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Onboard PCI/PCI-E Devices Configuration
JMicron 36x ATA Co ntroller [Enabled]
Onboard IEEE1394 C ontroller [Enabled]
Onboard PCIE Giga LAN [Auto]
Onboard LAN Boot ROM [Disabled]
Onboard LAN MAC ID :
Select ATA Contr oller
Operate Mode
JMicron 36x ATA Controller
This item allows you to select ATA controller operate mode.
Options: Enabled (Default) / Disabled
Onboard IEEE 1394 Controller
This item allows you to activate IEEE 1394 Controller.
Options: Enabled (Default) / Disabled
Onboard PCIE Giga LAN
This item allows you to control the onboard LAN.
Options: Auto (Default) / Enabled / Disabled
Onboard LAN Boot Rom
This item allows you to select the Onboard LAN Boot ROM.
Options: Disabled (Default) / Enabled
Onboard LAN MAC ID
This item shows the LAN MAC ID.
