TH55 HD BIOS Manual
40
PCH PLL Voltage
This item allows you to select PCH PLL Voltage control.
Options: Auto (Default) / 1.100V ~ 2.030V (Interval: 0.015V)
PCH Voltage
This item allows you to select PCH Voltage control.
Options: 1.10 V (Default) / 1.15 V / 1.20 V / 1.25 V
IGD Voltage
This item allows you to select Onboard Voltage control.
Options: Auto (Default) / 1.18V ~ 1.78V (Interval: 0.02V)
Intel PPM Configuration
BIOS SETUP UTILITY
O.N.E
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Intel PPM Configuration
Intel(R)SpeedStep(tm) tech [Enabled]
Intel
Intel C-STATE tech [Enabled]
C State package limit setting [Auto]
C3 State [ACPI C2]
C6 State [Enabled]
C1 Auto Demotion [Enabled]
C3 Auto Demotion [Enabled]
(R)Turbo Mode tech [Enabled]
(R)
Factory default TDC limit value :
Factory default TDP limit value :
Disabled: Disable GV3
Enable: Enable GV3
Intel(R) SpeedStep(tm) tech
This item allows you to enable SpeedStep technology for better power saving.
SpeedStep is a technology built into some Intel processors that allows the clock
speed o f the processor to be dynamically changed by software.
Options: Enabled (Default) / Disabled
