Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
LGA 775
Intel Core2Duo / Core2Quad /
Pent iu m Dual-Core / C eleron Dual-Core /
Celeron 4xx processor
(Maximum Watt: 95W)
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization Technology
FSB
Support 800 / 1066 / 1333 MHz
Chipset
Intel G41
Intel ICH7
Super I/O
ITE 8718F
Provides the most commonly used leg acy
Super I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
Hardware Monitor Controller
Fan Sp eed Controller
ITE's "S mart Guardian " funct ion
Main
Memory
DIMM Slots x 2
Each DIMM supports 256MB / 512MB /
1GB / 2GB DDR3
Max Memory Capicity 4GB
Dual Channel Mode DDR3 memory modu le
Supports DDR3 1066/800
Registered D IMM and ECC DIMM is not supported
Graphics
GMA X4500 Max Shared Video Memory is 256MB
IDE
Integrated IDE Contro ller
Ultra DMA 33 / 66 / 100 Bus Master Mode
supports PIO Mode 0~4
SATA 2
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 specif icat ion co mp liant
LAN
Realtek RTL8111DL
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
Codec
ALC662
5.1 channels audio out
High Definition Audio
PCI slot x2 Supports PCI expansion cards
Slots
PCI Express x 16 slot x1 Supports PCI-E x16 expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
Printer Port Connector x1 Each connector supports 1 Printer port
Serial port Connector x1 Connects to RS-232 Port
IDE Connector x1 Each connector supports 2 IDE device
SATA Connector x4 Each connector supports 1 SATA devices
On Board
Connectors
Front Panel Connector x1 Supports front panel facilities
