T41 HD
9
B. Memory Capacity
DIMM Socket
Location
DDR Module
Total Mem ory
Size
DDR2_A1 256MB/512MB/1GB/2GB/4GB
DDR2_B1 256MB/512MB/1GB/2GB/4GB
Max is 8GB.
C. Dual Channel Memory installation
Please refer to the following requirements to activate Dual Channel function:
Install memory module of the same density in pairs, shown in the table.
Dual Channel Status
DDR2_A1
DDR2_B1
Disabled O X
Disabled X O
Enabled O O
(O means memory installed, X means memory not installed.)
The DRAM bus width of the memory module must be the same (x8 or
x16)
