Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
LGA 775
Intel Core2Duo / Core2Quad / Celeron 4xx
/ Pentium Dual-core / Celeron Dual-core
processor
Supports Hyper-Threading / Execute Disable Bit /
Enhanced Intel Sp eedStep® / Int el Architecture-64 /
Extended Memory 64 Technology / Virtualization
Technology
FSB 800 / 1066 / 1333 MHz
Chipset
Intel G41 A3
Inte l ICH7
Super I/O
ITE 8718F
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control init iatives ,
Hardware Monitor Controller
Fan Sp eed Contro ller
ITE's "S mart Guard ian " function
Main
Memory
DIMM Slots x 2
Each DIMM supports 256MB / 512MB /
1GB / 2GB / 4GB DDR2
Max Memory Capacity 8GB
Dual Channel Mode DDR2 memory modu le
Supports DDR2 800/667
Registered DIMM and ECC DIMM is not supported
Graphics GMA X4500 Max Shared Video Memory is 256MB
IDE Integr ated IDE Contro ller
Ultra DMA 33 / 66 / 100 Bus Master Mode
supports PIO Mode 0~4
SATA 2 Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 specificat ion co mp liant
LAN Realtek RTL 8111DL
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
Codec
ALC662
5.1 channels audio out
High Definition Audio
PCI slot x3 Supports PCI expansion cards
PCI Express x 16 slot x1 Supports PCI-E x16 expansion cards
Slots
PCI Express x 1 slot x2 Supports PCI-E x1 expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
IDE Connector x1 Each connector supports 2 IDE device
SATA Connector x4 Each connector supports 1 SATA devices
Front Panel Connector x1 Supports front panel facilities
On Board
Connectors
Front Audio Connector x1 Supports front panel audio function
