TP45D2-A7/TP43D2-A7 BIOS Manual
17
Intel VT-d
Virtualization Technology for Directed I/O (VT-d) extends Virtualization
Technology (VT) roadmap, by providing hardware assists for virtualization solution.
VT-d can help end users improve security and reliability of the systems and also
improve performance of I/O devices in virtualized environment.
Options: Disabled (Default) / Enabled
USB Configuration
This item shows the USB controller and using USB device information.
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Enables support for
legacy USB. AUTO
option disables
legacy support if
no USB devices are
connected.
USB Configuration
USB Devices Enabled:
Module Version - 2.24.2-13.4
Legacy USB Support [Ena bled]
USB 2.0 Controller Mode [HiS peed]
BIOS EHCI Hand-Off [Ena bled]
> USB Mass Storage Device Configu ration
Legacy USB Support
This item determines if the BIOS should provide legacy support for USB devices
like the keyboard, mouse, and USB drive. This is a useful feature when using such
USB devices with operating systems that do not natively support USB (e.g.
Microsoft DOS or Windows NT).
Options: Enabled (Default) / Disabled
USB 2.0 Controller Mode
This item allows you to select the operation mode of the USB 2.0 controller.
Options: HiSpeed (Default) USB 2.0-480Mbps
FullSpeed USB 1.1-12Mbps
