TP45D2-A7/TP43D2-A7 BIOS Manual
30
6 O.N.E Menu
This submenu allows you to change voltage and clock of various devices.
(However, we suggest you to use the default setting. Changing the voltage and clock
improperly may damage the device.)
Notice
z Beware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset O.N.E
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Over-Clocking Navigator setting
WARNING: Setting wrong values in below sections
may cause system to malfunction.
=========== Automate OverClock System ===========
============ Manual OverClock System ============
Over-Clocking Navigator [Normal]
Memory Test [Disabled]
Auto OverClock System [V6-Tech Engine]
Intel(R) SpeedStep(tm) tech [Enabled]
Ratio CMOS Setting [ x10.0]
CPU Frequency Setting [266]
Over Clock Retry Count [3]
FSB(Bsel) To NorthBridge Latch [Auto]
DRAM Frequency [Auto]
DDR2 Enhanced Mode [Auto]
> DRAM Timing Configuration
> Clock Gen Configuration
> ALL Voltage Configuration
Exit
Options
Normal
Automate OverClock
Manual OverClock
OverClock Navigator
OverClock .Navigator is designed for beginners in overclock field.
Based on many test and experiments from Biostar Engineer Team, OverClock
Navigator provides 3 default overclock configurations that are able to raise the
system performance.
Options: Normal (Default) / Automate OverClock / Manual OverClock
