TP45E Combo/TP43E Combo
9
B. Memory Capacity
DIMM Socket
Location
Memory Module
Total Mem ory
Size
DDR3_A1 256MB/512MB/1GB/2GB
DDR2_B1 256MB/512MB/1GB/2GB/4GB
DDR3_A2 256MB/512MB/s1GB/2GB
DDR2_B2 256MB/512MB/1GB/2GB/4GB
DDR3 Max: 4GB
DDR2 Max: 8GB
C. Dual Channel Memory installation
Please refer to the following requirements to activate Dual Channel function:
Install memory module of the same density in pairs, shown in the table.
Dual Channel Status
DDR3_A1
DDR2_B1 DDR3_A2 DDR2_B2
Enabled O X O X
Enabled X O X O
(O means memory installed, X means memory not installed.)
The DRAM bus width of the memory module must be the same (x8 or
x16)
Attention: Do NOT install DDR2 & DDR3 memory modules
simultaneously, or the system will not work normally.
