Capacity Range Si38-304
6 General Information
4. Capacity Range
Outdoor Units
Indoor Units
Capacity Range 5HP 8HP 10HP 12HP 14HP 16HP 18HP 20HP 22HP 24HP 26HP
RX (Y) 5M 8M 10M 12M 14M 16M 18M 20M 22M 24M 26M
No of Indoor Units
to be Connected
81316 20 22 32
Total Capacity
Index of Indoor
Units to be
Connected
62.5
~
162.5
100
~
260
125
~
325
150
~
390
175
~
455
200
~
520
225
~
585
250
~
650
275
~
715
300
~
780
325
~
845
Capacity Range 28HP 30HP 32HP 34HP 36HP 38HP 40HP 42HP 44HP 46HP 48HP
RX (Y) 28M 30M 32M 34M 36M 38M 40M 42M 44M 46M 48M
No of Indoor Units
to be Connected
32 34 36 38 40
Total Capacity
Index of Indoor
Units to be
Connected
350
~
910
375
~
975
400
~
1040
425
~
1105
450
~
1170
475
~
1235
500
~
1300
525
~
1365
550
~
1430
575
~
1495
600
~
1560
Capacity Range
0.8
HP
1
HP
1.25
HP
1.6
HP
2
HP
2.5
HP
3
HP
3.2
HP
4
HP
5
HP
8
HP
10
HP
Capacity Index 20 25 31.25 40 50 62.5 71 80 100 125 200 250
Ceiling Mounted
Cassette Type
(Double Flow)
FXC 20L 25L 32L 40L 50L 63L — 80L — 125L — —
Ceiling Mounted
Cassette Type
(Multi Flow)
FXF — 25L 32L 40L 50L 63L — 80L 100L 125L — —
Ceiling Mounted
Cassette Corner
Type
FXK — 25L 32L 40L — 63L — — — — — —
Ceiling Mounted Low
Silhouette Duct Type
FXYD 20KA 25KA 32KA 40KA 50KA 63KA — — — — — —
Ceiling Mounted
Built-In Type
FXS 20L 25L 32L 40L 50L 63L 80L 100L 125L — — —
Ceiling Mounted
Built-In (Rear
Suction) Type
FXYB 20K 25K 32K 40K 50K 63K — 80K 100K 125K — —
Ceiling Mounted
Duct Type
FXM — — — 40L 50L 63L — 80L 100L 125L 200L 250L
Ceiling Suspended
Type
FXH — — 32L — — 63L — — 100L — — —
Wall Mounted Type
FXA 20L 25L 32L 40L 50L 63L — — — — — —
Floor Standing Type
FXL 20L 25L 32L 40L 50L 63L — — — — — —
Concealed
Floor Standing Type
FXN 20L 25L 32L 40L 50L 63L — — — — — —
