Specifications Si38-304
10 Specifications
Notes:
+
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
+
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
+
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name RXY14MY1(E) RXY16MY1(E)
+
1 Cooling Capacity (19.5°CWB)
kcal / h 35,500 40,000
Btu / h 141,000 158,000
kW 41.2 46.4
+
2 Cooling Capacity (19.0°CWB) kW 40.0 45.0
+
3 Heating Capacity
kcal / h 35,500 40,000
Btu / h 142,000 154,000
kW 41.5 45.0
Casing Color
Y1 Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Y1E Light Camel (2.5Y6.5/1.5) Light Camel (2.5Y6.5/1.5)
Dimensions: (H×W×D) mm 1600×1240×765 1600×1240×765
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h 19.36+14.68+14.68 19.36+14.68+14.68
Number of Revolutions r.p.m 6480, 2900×2 6480, 2900×2
Motor Output×Number
of Units
kW (2.0+4.5+4.5)×1 (3.0+4.5+4.5)×1
Starting Method Direct on Line Direct on Line
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×1 0.75×1
Air Flow Rate m³/min 210 210
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ15.9 (Brazing Connection) φ15.9 (Brazing Connection)
Gas Pipe mm φ34.9 (Brazing Connection) φ34.9 (Brazing Connection)
Oil Equalizing Pipe mm — —
Machine Weight kg 331 333
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
Defrost Method Deicer Deicer
Capacity Control % 10~100 10~100
Refrigerant
Refrigerant Name R22 R22
Charge kg 17.1 18.6
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator
Oil
SUNISO 4GSDID-K SUNISO 4GSDID-K
Charge Volume L 1.9+1.6+1.6 1.9+1.6+1.6
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. 4D038974A 4D038975A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
