Si38-304 Option List
Appendix 313
4.2 Option Lists (Outdoor Unit)
RXY5 ~ 16MY1, YL, TL (E), RX5 ~ 10MY1 (E)
3D039850
3D041582
RXY18 ~ 32MY1, YL, TL (E), RX18 ~ 32MY1 (E)
3D039851
3D041583
RXY34 ~ 48MY1, YL, TL (E), RX34 ~ 48MY1 (E)
3D039852
3D041584
Optional accessories
RXY5MY1, YL, TL
RX5MY1
RXY5MY1E, YLE, TLE
RX5MY1
E
RXY8MY1, YL, TL
RXY10MY1, YL, TL
RX8MY1
RX10MY1
RXY8MY1E, YLE, TLE
RXY10MY1E, YLE, TLE
RX8MY1E
RX10MY1E
RXY12MY1, YL, TL
RXY14MY1, YL, TL
RXY16MY1, YL, TL
RX12MY1
RX14MY1
RX16MY1
RXY12MY1E, YLE, TLE
RXY14MY1E, YLE, TLE
RXY16MY1E, YLE, TLE
RX12MY1E
RX14MY1E
RX16MY1E
Cool/Heat Selector KRC19-26A (For Heat Pump)
Fixing box KJB111A
Distributive
Piping
Refnet header
KHRJ26K11H, KHRJ26K17H
(MAX. 4 branch) (MAX. 8 branch)
KHRJ26K11H, KHRJ26K17H
(MAX. 4 branch) (MAX. 8 branch)
KHRJ26K18H, KHRJ26K37H
(MAX. 6 branch) (MAX. 8 branch)
KHRJ26K11H, KHRJ26K17H,
(MAX. 4 branch) (MAX. 8 branch)
KHRJ26K18H
(MAX. 6 branch)
KHRJ26K37H, KHRJ26K40H
(MAX. 8 branch) (MAX. 8 branch)
Refnet joint KHRJ26K11T, KHRJ26K17T
KHRJ26K11T, KHRJ26K17T
KHRJ26K18T, KHRJ26K37T
KHRJ26K11T, KHRJ26K17T,
KHRJ26K18T, KHRJ26K37T,
KHRJ26K40T
Pipe size reducer — KHRJ26K40TP, KHRJ26K40HP
Central drain pan kit KWC26B160 KWC26B160E KWC26B280 KWC26B280E KWC26B450 KWC26B450E
Optional accessories
RXY18MY1, YL, TL
RXY20MY1, YL, TL
RX18MY1
RX20MY1
RXY18MY1E, YLE, TLE
RXY20MY1E, YLE, TLE
RX18MY1E
RX20MY1E
RXY22MY1, YL, TL
RX22MY1
RXY22M
Y1E,
YLE, TLE
RX22MY1E
RXY24MY1, YL, TL
RXY26MY1, YL, TL
RX24MY1
RX26MY1
RXY24MY1E, YLE, TLE
RXY26MY1E, YLE, TLE
RX24MY1E
RX26MY1E
RXY28MY1, YL, TL
RXY30MY1, YL, TL
RXY32MY1, YL, TL
RX28MY1
RX30MY1
RX32MY1
RXY28MY1E, YLE, TLE
RXY30MY1E, YLE, TLE
RXY32MY1E, YLE, TLE
RX28MY1E
RX30MY1E
RX32MY1E
Cool/Heat Selector KRC19-26A (For Heat Pump)
Fixing box KJB111A
Distributive
Piping
Refnet header
KHRJ26K11H, KHRJ26K17H, KHRJ26K18H, KHRJ26K37H, KHRJ26K40H
(MAX. 4 branch) (MAX. 8 branch) (MAX. 6 branch) (MAX. 8 branch) (MAX. 8 branch)
Refnet joint
KHRJ26K11T, KHRJ26K17T, KHRJ26K18T, KHRJ26K37T,
KHRJ26K40T
KHRJ26K11T, KHRJ26K17T, KHRJ26K18T, KHRJ26K37T,
KHRJ26K40T, KHRJ26K75T
Outdoor unit multi
connection piping kit
BHF22M90
Pipe size reducer KHRJ26K40TP, KHRJ26K40HP KHRJ26K40TP, KHRJ26K75TP, KHRJ26K40HP
Central drain pan kit KWC26B280×2 KWC26B280E×2
KWC26B280
KWC26B450
KWC26B280E
KWC26B450E
KWC26B280
KWC26B450
KWC26B280E
KWC26B450E
KWC26B450×2 KWC26B450E×2
Optional accessories
RXY34MY1, YL, TL
RX34MY1
RXY34MY1E, YLE, TLE
RX34MY1E
RXY36MY1, YL, TL
RX36MY1
RXY36MY1E,
YLE, TLE
RX36MY1E
RXY38MY1, YL, TL
RXY40MY1, YL, TL
RXY42MY1, YL, TL
RX38MY1
RX40MY1
RX42MY1
RXY38MY1E, YLE, TLE
RXY40MY1E, YLE, TLE
RXY42MY1E, YLE, TLE
RX38MY1E
RX40MY1E
RX42MY1E
RXY44MY1, YL, TL
RXY46MY1, YL, TL
RXY48MY1, YL, TL
RX44MY1
RX46MY1
RX48MY1
RXY44MY1E, YLE, TLE
RXY46MY1E, YLE, TLE
RXY48MY1E, YLE, TLE
RX44MY1E
RX46MY1E
RX48MY1E
Cool/Heat Selector KRC19-26A (For Heat Pump)
Fixing box KJB111A
Distributive
Piping
Refnet header
KHRJ26K11H, KHRJ26K17H, KHRJ26K18H, KHRJ26K37H, KHRJ26K40H
(MAX. 4 branch) (MAX. 8 branch) (MAX. 6 branch) (MAX. 8 branch) (MAX. 8 branch)
Refnet joint KHRJ26K11T, KHRJ26K17T, KHRJ26K18T, KHRJ26K37T, KHRJ26K40T, KHRJ26K75T
Outdoor unit multi
connection piping kit
BHF22M135
Pipe size reducer
KHRJ26K40TP, KHRJ26K75TP
KHRJ26K40HP
KHRJ26K40TP, KHRJ26K75TP, KHRJ26K76TP, KHRJ26K40HP
Central drain pan kit
KWC26B280×2
KWC26B450
KWC26B280E×2
KWC26B450E
KWC26B280×2
KWC26B450
KWC26B280E×2
KWC26B450E
KWC26B280
KWC26B450×2
KWC26B280E
KWC26B450E×2
KWC26B450×3 KWC26B450E×3
