8 | Chapter 2: Hardware installaon

Step 1: Align a DIMM on the slot such that the notch on the DIMM matches the break on the

Slot.

Step 2: Insert the DIMM rmly into the slot unl the retaining chip snap back in place and the

DIMM is properly seated.

Note

 IftheDIMMdoesnotgoinsmoothly,donotforceit.Pullitallthewayoutandtryagain.

Memory Capacity

DIMM Socket Locaon DDR3L Module Total Memory Size

DIMMA1 512MB/1GB/2GB/4GB/8GB

Max is 16GB.

DIMMB1 512MB/1GB/2GB/4GB/8GB

Dual Channel Memory Installaon

Please refer to the following requirements to acvate Dual Channel funcon:

Install memory module of the same density in pairs, shown in the table.

Dual Channel Status DIMMA1 DIMMB1

Disabled O X

Enabled O O

(O means memory installed, X means memory not installed.)

Note

 Wheninstallingmorethanonememorymodule,werecommendtousethesamebrandand

capacitymemoryonthismotherboard.
