1.4 Rear Panel Connectors

B450MX

B450MX-S

Note



B450MX:DVI-D/VGA/HDMIoutputrequireanAMDfamilyprocessorwithintegratedgraphics.

B450MX-S:HDMIoutputrequireanAMDfamilyprocessorwithintegratedgraphics.



SincetheaudiochipsupportsHighDenionAudioSpecicaon,thefunconofeachaudiojack

canbedenedbysoware.Theinput/outputfunconofeachaudiojacklistedaboverepresents

thedefaultseng.However,whenconnecngexternalmicrophonetotheaudioport,pleaseuse

theLineIn(Blue)andMicIn(Pink)audiojack.



Maximumresoluon

DVI-D:1920x1200@60Hz

VGA:1920x1200@60Hz

HDMI:4096x2160@30Hz,compliantwithHDMI1.4



TheAthlon200GECPUwillnotsupportVGAPortsignals.



WhenusingthefrontHDaudiojackandplugintheheadset,therearsoundwillbeautomacally

Disabled.
