4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Socket AM4 supports AMD® A-series APU, Ryzen APU / Ryzen CPU
* Please refer to www.biostar.com.tw for CPU support list.
Chipset AMD® A320
Memory
Supports Dual Channel DDR4 1866/2133/2400/2667
2 x DDR4 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 4/8/16 GB DDR4 module
* DDR4 - 2667 only for Ryzen CPU.
* Please refer to www.biostar.com.tw for Memory support list.
Storage 4x SATA III Connector (6Gb/s) : Supports AHCI & RAID 0, 1, 10
LAN
Realtek RTL 8111H
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC887
7.1 Channels, High Denion Audio
USB
4x USB 3.1 Gen1 (5Gb/s) port (2 on rear I/Os and 2 via internal headers)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion Slots
2x PCIe 3.0 x1 Slot
1x PCIe 3.0 x16 Slot (When using APU, the bandwidth is x8 speed)
Rear I/Os
A320MH PRO:
1x PS/2 Mouse
1x PS/2 Keyboard
1x HDMI Port
1x VGA Port
1x LAN port
2x USB 3.1 Gen1 (5Gb/s) Port
2x USB 2.0 Port
3x Audio Jack
A320MD PRO:
1x PS/2 Mouse
1x PS/2 Keyboard
1x DVI-D Port
1x VGA Port
1x LAN port
2x USB 3.1 Gen1 (5Gb/s) Port
2x USB 2.0 Port
3x Audio Jack
Internal I/Os
4x SATA III 6.0Gb/s Connector
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.1 Gen1 (5Gb/s) Header (each header supports 2 USB 3.1 Gen1 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x COM Serial Header
1x Clear CMOS Header
Form Factor uATX Form Factor, 184.01 mm x 226 mm
OS Support
Windows 7(64bit) / 10(64bit)
Biostar reserves the right to add or remove support for any OS with or without noce.
