2. Advanced Menu | 13
TB350-BTC / TA320-BTC
DRAM Memory Mapping
Chipselect Interleaving
This item Interleave memory blocks across the DRAM chip selects for node 0.
Opons: Auto (Default) / Disabled
BankGroupSwap
This item allows you to set BankGroupSwap funcon.
Opons: Auto (Default) / Enabled / Disabled
Address Hash Bank
This item enabled or disabled bank address hashing.
Opons: Auto (Default) / Enabled / Disabled
Address Hash CS
This item enabled or disabled CS address hashing.
Opons: Auto (Default) / Enabled / Disabled
