Motherboard Manual
2
1.3 Motherboard Specifications
Specifications
CPU Support
Socket FM2+ supports AMD FM2+/FM2 A-series APU
Maximum CPU TDP (Thermal Design Power): 100Watt
* Please refer to www.biostar.com.tw for CPU support list.
Chipset AMD A68H FCH / AMD A70M FCH
Memory
Supports Dual Channel DDR3 800/ 1066/ 1333/ 1600/ 1866/ 2133/ 2400(OC)/
2600(OC)
2 x DDR3 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8/ 16 GB DDR3 module
* Please refer to www.biostar.com.tw for Memory support list.
Storage
AMD A68H FCH
4x SATA 6Gb/s Connector
Supports RAID 0,1,10 & AHCI
AMD A70M FCH
4x SATA 6Gb/s Connector
Supports RAID 0,1 & AHCI
LAN
Realtek RTL 8111G (A68MDP-LSP/A68MGP-LSP/A70MGP-LSP)
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
Realtek RTL 8106E (A68MLP)
10/ 100 Mb/s auto negotiation, Half / Full duplex capability
Audio Codec
ALC662
5.1 Channels, High Definition Audio
USB
AMD A68H/ A70M FCH
2x USB 3.0 port (2 on rear I/Os)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion Slots
1x PCI Slot
1x PCIe x1 Slot
1x PCIe 3.0 x16 Slot (Only FM2+ processors can support PCIe 3.0)
Rear I/Os
1x PS/2 Mous
1x PS/2 Keyboard
1x DVI Port (A68MDP-LSP)
1x VGA Port
1x LAN port
2x USB 3.0 Port
2x USB 2.0 Port
3x Audio Jack
Internal I/Os
4x SATA 6.0Gb/s Connector
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
