TA970XE
49
Especificación
Cabecera de ventilador de CPU X1 Fuente de alimentación de ventilador de CPU (con
función Smart Fan)
Cabecera de ventilador de sistema X2 Fuente de alimentación de ventilador de sistema
Cabecera de borrado de CMOS X1
Conector USB2.0 X2 Cada conector soporta 2 puertos USB2.0 frontales
Cabecera IEEE 1394 x1
Conector Puerto de impresora X1 Cada conector soporta 1 Puerto de impresora
Puerto serie X1
Conector de alimentación X1
(24 patillas)
Conector de alimentación X1
(4 patillas)
Panel
trasero de
E/S
Teclado / Ratón PS/2 X1
Coaxial + óptico Salida S/PDIF x1
Puerto 1394 x1
Puerto eSATA X1
Puerto de red local X1
Puerto USB2.0 X6
Puerto USB3.0 X2
Conector de sonido X6
Tamaño d e
la placa
305 mm. (A) X 225 mm. (H)
Soporte de
sistema
operativo
Windows XP / Vista / 7
Biostar se reserva el derecho de añadir o retirar el
soporte de cualquier SO con o sin aviso previo.
